What to expect during a UK heat pump installation
r covering UK home heating upgrades, heat pump economics, grant policy, and practical retrofit decisions.
Photo by alpha innotec on Pexels
If you are a UK homeowner considering a heat pump, you have probably already done some research and discovered that the technology works, that grants exist, and that your neighbours are asking questions.
What you may not have found is a straightforward account of what actually happens during an installation — the surveys, the disruption, the paperwork, and the moment when your home switches to a low-carbon heating system for the first time.
This article provides that account.
It covers every stage from initial enquiry through to commissioning, drawing on the standard practices of MCS-certified installers and the requirements of the Boiler Upgrade Scheme (BUS).
Why installation complexity matters more than equipment cost
Heat pumps are not like gas boilers.
A gas boiler installation is essentially a straight swap: remove the old unit, fit the new one, connect the gas line, done.
A heat pump installation is a system change.
It affects how your entire home holds and distributes heat, and it interacts with your insulation, your hot water cylinder, your radiators or underfloor heating, and your electricity tariff.
That complexity means the installation process is longer, more varied, and more dependent on good planning than most homeowners expect.
The financial case for getting this right is substantial.
A well-installed air source heat pump in a reasonably insulated UK home will achieve a Seasonal Coefficient of Performance (SCOP) of around 2.5 to 3.5, meaning each unit of electricity consumed produces two and a half to three and a half units of heat.
A poorly installed system might deliver a SCOP of 1.8 or lower, making the running costs comparable to electric storage heaters.
The difference between those two outcomes is almost entirely determined during the design and installation phase.
Key figure:
A correctly installed heat pump typically achieves a Seasonal Coefficient of Performance (SCOP) of 2.5 to 3.5.
An incorrectly specified or installed system can fall to 1.8 or below, substantially increasing running costs and negating the environmental benefit of switching away from fossil fuels.
Stage 1: The initial enquiry and choosing an installer
The process begins with choosing the right installer, and in the UK this means finding someone MCS (Microgeneration Certification Scheme) certified.
MCS is the industry benchmark for quality in small-scale renewable energy installations, and it is also a requirement for accessing the Boiler Upgrade Scheme grant.
You cannot claim the BUS without using an MCS-certified installer, so this is not a box-ticking exercise — it is the foundation of everything that follows.
Expect to receive at least two or three quotes.
A reputable installer will not quote from a phone call.
They will want to visit the property, inspect the existing heating system, assess the fabric of the building, and understand how you use your home.
If an installer offers a fixed price over the phone based on nothing more than the number of bedrooms, treat that as a warning sign.
Questions worth asking at this stage include: whether the installer has experience with properties similar to yours in construction and age, what makes up their quote, and what their after-installation support looks like.
The cheapest quote is not necessarily the best — installation quality varies enormously, and the cost of fixing a poor installation can exceed the savings from a lower upfront price.
Stage 2: The survey and system design
Once you have chosen an installer, a detailed technical survey follows.
This is the most important step that most homeowners underestimate.
The survey is where the system is actually designed, and it determines how well the heat pump will perform for the next twenty years.
A thorough survey should include a heat loss calculation for your property.
This is a room-by-room assessment of how much heat your home loses through walls, roofs, floors, windows, and ventilation.
The calculation uses the specific U-values of your building fabric and the internal and external design temperatures to determine the heat output required at design conditions — typically minus three degrees Celsius outside temperature for most of the UK.
This figure tells the installer exactly how much heat the pump needs to generate on the coldest day of the year.
"The heat loss calculation is not bureaucracy.
It is the engineering foundation of the entire system.
Skip it and you are guessing." — Industry guidance from the MCS Technical Standards for Heat Pumps, 2024.
The survey will also assess your existing heat distribution system.
Radiators in a heat pump system typically need to be larger than those in a gas boiler system because heat pumps run at lower water temperatures — usually between 35°C and 55°C on the flow pipe, compared to 70°C to 80°C for a gas boiler.
In a poorly insulated Victorian terrace, this can mean significant radiator upgrades.
In a newer home with good insulation and underfloor heating already in place, the existing system may be adequate.
Hot water provision is another key consideration.
Most UK homes use a cylinder for hot water storage.
Heat pumps can heat domestic hot water, but they are most efficient when producing heating at lower temperatures.
A dedicated hot water cylinder with a larger coil surface area or a dedicated immersion heater for legionella control (heating to 60°C periodically) is usually specified.
Some installers recommend a twin-coil cylinder that allows the heat pump to handle space heating while a different heat source tops up hot water, though this adds cost and complexity.
Stage 3: The Boiler Upgrade Scheme and grant process
If you qualify, the Boiler Upgrade Scheme provides a grant of £7,500 towards the installation of an air source heat pump, or £7,500 for a ground source heat pump.
The grant is paid directly to your MCS-certified installer, who deducts it from your invoice.
You do not need to apply to the government first — your installer handles the grant claim through the MCS installer portal.
Grant update: The Boiler Upgrade Scheme (BUS) offers £7,500 for air source heat pump installations and £7,500 for ground source heat pump installations in England and Wales as of 2024.
Scotland and Northern Ireland operate separate schemes with different grant levels.
Always verify current rates with your installer or the applicable energy authority before committing.
To qualify, your property must have a valid Energy Performance Certificate (EPC) and you must not have received BUS support previously for the same property.
The property does not need to have previously had a gas boiler — many off-gas properties have been successfully upgraded under BUS.
If your property has an EPC of G, F, or E, you may need to carry out certain recommended insulation improvements first, as the scheme has fabric efficiency requirements.
Be aware that grant funding is finite and allocated in batches.
Availability can fluctuate.
Your installer can advise on current funding status, but it is worth beginning the enquiry process early rather than waiting until you are ready to proceed immediately.
Stage 4: The installation itself
For an air source heat pump in a typical UK semi-detached home, the physical installation work typically takes between three and five days.
A ground source installation is considerably more involved and can take two weeks or longer, particularly if it involves digging trenches or drilling boreholes.
The installation process for an air source heat pump generally follows this sequence:
- Day 1:Removal of the existing boiler (if applicable), assessment of pipework routes, and positioning of the outdoor unit.
The outdoor unit is placed on a flat surface — usually a concrete pad or purpose-made stand — at ground level or mounted on a wall bracket.
It needs adequate clearance for airflow and should be positioned away from bedrooms to minimise noise disturbance, particularly at night.
- Day 1-2:
Installation of the indoor unit (the hydraulic module), connection to the heat distribution system, and routing of refrigerant lines between the indoor and outdoor units.
This work involves working with refrigerant gas, which requires trained and certified engineers.
- Day 2-3:
Hot water cylinder installation or modification, connection to the electrical supply, and integration with existing controls.
Smart controls are a significant part of a heat pump installation — the system needs to understand when to heat, when to maintain temperature, and when to produce hot water.
- Day 3-4:
Filling and pressure testing of the heating circuit, checking for leaks, and connecting to the consumer unit with a dedicated circuit.
The electrician will ensure the supply can handle the additional load.
- Day 4-5:
Commissioning: the system is started up, parameters are set, the heat pump is configured for your specific property, and performance is verified against the design specification.
Disruption during the installation is moderate but should not be underestimated.
The work involves drilling, pipework, and electrical connections.
Your central heating may be offline for a day or two, so plan accordingly, particularly in winter.
Your installer should tell you in advance exactly when the heating will be unavailable.
Pro Tip:
Ask your installer to show you the commissioning settings before they leave.
Specifically, check the flow temperature setpoint, the weather compensation curve (if fitted), and the hot water schedule.
Understanding these parameters will help you operate the system efficiently and troubleshoot minor issues without calling out an engineer.
Most reputable installers will walk you through these settings as part of the handover.
Stage 5: Commissioning and handover
Commissioning is the process of setting up the heat pump so that it performs as designed.
It is not simply turning the system on.
A proper commissioning process involves configuring the heat pump's control parameters, setting the flow temperature based on the heat loss calculation, adjusting the weather compensation curve if the system uses one, and verifying that the hot water reaches 55°C to 60°C at the cylinder top.
Your installer should carry out a commissioning check that includes verifying the refrigerant charge, checking the expansion vessel pre-charge, balancing the radiators or underfloor heating circuits, and testing the system's performance against the design heat load.
They should leave you with documentation including the commissioning record, the installation manual, the warranty details, and contact information for service and support.
One common issue at commissioning is radiator balancing.
In a heat pump system running at lower flow temperatures, getting the flow of hot water evenly distributed across all radiators is more critical than in a gas boiler system.
If one room is colder than others after installation, it usually means the system needs rebalancing, not that the heat pump is undersized.
Stage 6: The weeks after installation — bedding in and optimisation
Your heat pump will not perform at its best immediately after installation.
The system and your home need time to adjust to each other.
During the first two to four weeks, expect to fine-tune the controls as you learn how your property responds to different settings.
Weather compensation controls are particularly worth understanding.
These adjust the flow temperature of the heat pump based on the outside temperature, so that on milder days the system uses less energy than on cold days.
A correctly configured weather compensation curve will reduce your energy consumption significantly compared to a system running at a fixed temperature regardless of conditions.
Your installer should offer a follow-up visit or phone call after the first month to check that everything is performing as expected and to make any adjustments.
If they do not offer this, ask for it.
The difference between a system that works and a system that works efficiently can be a few parameter adjustments that take twenty minutes to make.
Real-world example:
A three-bedroom semi-detached house in Bristol, built in the 1990s with cavity wall insulation and double glazing, had a heat loss of approximately 7kW at design conditions.
The installer specified a 9kW Daikin Altherma 3 R heat pump with a 200-litre cylinder.
The system ran at a flow temperature of 42°C on the coldest day.
Annual electricity consumption for heating and hot water was approximately 3,200 kWh, giving estimated annual running costs of around £950 with a standard electricity tariff in 2024.
A comparable property with the same heat pump but without commissioning optimisation consumed over 4,500 kWh annually.
Understanding the timeline from enquiry to completion
The entire process from first contacting an installer to having a fully commissioned and optimised system typically takes between six and twelve weeks.
The longest delays are usually in survey scheduling and in waiting for MCS registration and grant processing.
The installation work itself is relatively quick once the survey is complete.
If your installation requires significant preparatory work — upgrading radiators, improving loft insulation, or installing a new hot water cylinder — factor that into your timeline.
Some homeowners choose to carry out fabric improvements before the heat pump installation; others do them afterwards.
Either approach is valid, but doing them before means the heat pump is sized correctly from day one.
Ground source heat pump installations have a longer timeline due to the groundworks involved.
A horizontal loop system requires trenches to be dug, which may need scheduling around ground conditions.
A vertical borehole system requires specialist drilling equipment and potentially planning permission.
Expect a minimum of three months from initial enquiry to completion for a ground source system.
Summary: What to know before you commit
A successful heat pump installation in a UK home depends on three things: proper sizing through a heat loss calculation, quality installation by MCS-certified engineers, and careful commissioning that matches the system to your property.
The process takes longer than a boiler replacement and involves more decisions along the way, but it is entirely manageable if you know what to expect.
The Boiler Upgrade Scheme substantially reduces the upfront cost, but the running costs — and the satisfaction you get from a well-functioning low-carbon heating system — depend almost entirely on the quality of the installation process rather than the grant you received.
Pro Tip:
Before signing any installation contract, ask your installer for the heat loss calculation and for evidence that the heat pump model selected can meet your heat demand at an appropriate flow temperature for your distribution system.
A reputable installer will provide both without hesitation.
If they cannot explain how they sized the system, walk away.
Installation stage comparison
| Stage | Typical duration | Key actions | What to check |
|---|---|---|---|
| Initial enquiry and choosing installer | 1–3 weeks | Obtain 2–3 quotes, verify MCS certification, check installer experience with similar properties | Installer credentials, quotation detail, BUS eligibility |
| Technical survey and system design | 1–2 weeks | Heat loss calculation, property inspection, hot water and distribution assessment | Heat loss report, proposed system specification, radiator upgrade requirements |
| Grant application and order processing | 1–4 weeks | BUS grant submission, equipment ordering, schedule confirmation | Grant confirmation, delivery date, installation dates |
| Physical installation (air source) | 3–5 days | Boiler removal, outdoor unit placement, pipework, electrical connections, cylinder install | Clear working areas, access for equipment, scheduling of heating outage |
| Commissioning and handover | 1 day | System start-up, parameter configuration, performance verification, customer walkthrough | Commissioning record, warranty documents, control settings explanation |
| Post-installation optimisation | 2–4 weeks | Fine-tuning of controls, radiator balancing, performance monitoring, follow-up visit | Comfort levels in all rooms, hot water temperature, energy consumption |
The heat pump installation journey is well within reach for most UK homeowners who are willing to invest time in understanding the process and choosing an installer who treats the work as a system design challenge rather than a product sale.
Done properly, it produces a heating system that is quieter, more efficient, and better suited to a low-carbon future than any fossil fuel alternative available today.
